The ZyCast CT2IP-8032 is an all-inclusive high quality DVB-T/T2 to IPTV Converter. Designed to allow system integrators to receive multiple DVB-T/T2 signals and quicklyand easily convert these signals to produce a high quality IPTV Distribution system. The CT2IP-8032 is a highly flexible system allowing integrators to quickly receive, convert, and distribute a variety of commercial terrestrial channels.
|
Terrestrial |
Input |
F Female |
Number |
8 |
Loop Through |
8 |
|||
Frequency Range |
MHz |
VHF: 50.5 to 296.5 HF:306 to 858 |
||
Constellation |
DVB-T: QPSK, 16-QAM, 64 QAM DVB-T2: QPSK, 16 QAM, 64 QAM, 256 QAM |
|||
Bandwidth |
MHz |
6, 7, 8 (Factory Setting) |
||
Guard Interval |
DVB-T: ¼, ??, 1/16, 1/32 DVB-T2: ¼, 19/128, ??, 19/256, 1/16, 1/32, 1/128 |
|||
FEC Code Rate |
DVB-T: 1/4, 1/8, 1/16, 1/32 DVB-T2: 1/4, 19/128,1/8, 19/256, 1/16, 1/32, 1/128 |
|||
Transmission Mode |
DVB-T: 2k / 8k DVB-T2: 1k / 2k /4k / 8k / 16k / 32k |
|||
|
IP |
Connector |
RJ45 100 / 1000 Mbps Ethernet |
Number |
1 |
|
Streaming Protocols |
Unicast UDP / RTP |
|||
Multicast UDP / RTP | ||||
SPTS Streaming |
Number of Stream |
32 |
||
|
Hardware |
RAM (DDR3) |
MB |
128 |
|
Memory |
NAND Flash |
MB |
N / A |
|
|
LED |
Power LED |
1 x Green (ON) |
||
Indicator LEDs |
8 x Green (Input Signal Locked ) OFF (Input Signal Unlocked ) |
|||
|
General |
Configuration |
RJ45 10 / 100 Mbps Ethernet |
Web GUI |
|
Control Protocols |
HTTP / Restful API |
|||
Upgrade via Web GUI |
TBD |
|||
Power |
Watt |
50 |
||
Input Line Voltage |
VAC/ Hz |
95 ~ 264 / 50~60 |
||
Dimensions |
mm |
482.7w X 238d X 43.2h (Excluding Connectors) |
||
Weight |
kg |
4 |
||
