Sold Out
Please note the fuse has been taken out for transportation safety purpose because of the built in SLA battery. Please put the fuse in before you start to use the PM12.
Power supply: | 230 V AC, 50 Hz |
or 12 V DC via rechargeable battery or external source | |
Rechargeable. battery: | 12 V DC, 7.2 Ah Sealed Lead Acid (included) |
Battery operation: | 4-5 hours |
Recharging time: | 10-11 hours |
Dimensions (L x W x H): | 430 x 370 x 715 mm |
Amplifier: | |
Nominal power output: | 40 W RMS / 4 OHMS |
Maximum power output: | 90 W |
Inputs: | |
Mic, mono: | 2 x 6.3 mm jack, Lo-Z unbalanced, |
Line, stereo: | RCA L/R Hi-Z unbalanced |
Output: | |
Line, mono: | 2 x RCA unbalanced line output |
Sensitivity: | -40dBV (10 mVrms) |
Speaker system: | |
Components: | 30 cm woofer (12 inch) |
Maximum SPL: | 112 dB |
Sensitivity: | 14dBV (200 mVrms) |
Frequency response: | 80 – 15000 Hz |
Bass/treble control | 8dB cut/boost @ 100Hz-8K Hz |
Sensitivity: | -14dBV (200 mVrms) |
Reception modules: | |
Carrier frequency: | UHF |
Frequency: | 654-694 MHz |
Range: | Approx. 40 m |
Wireless microphones: | |
Frequency stability: | ±0.005 % |
RF power output: | 10 mW |
Polar pattern: | Omnidirectional |
Range: | Approx. 40 m |
Battery: | 2 x 1.5 V AA battery (included) |
Battery life: | 10 hours |
Dimensions (D x L): | 40 x 260 mm |
Bluetooth: | |
Carrier frequency: | 2.4 GHz |
Range: | Approx. 10 m |
Audio player: | |
Playback format: | MP3, WMA |
Storage media: | USB devices and SD(HC) cards up to 32 GB |
File system: | FAT32 |
Gross weight | 16.72 kg |
Net weight: | 14.72 kg |
Power consumption: | 35 W |
Size of woofer: | 30 cm (12 inch) |
