BIRCH PLYWOOD
All Delta-AX models use premium Baltic birch plywood construction.
Not only does this create a solid and durable cabinet, but it also contributes to the overall sound and character.
Delta-AX is also covered in our most durable and hard wearing Rhino Rock paint finish. This ensures that a Delta-AX will always look as good as the day you unboxed it.
ROUTED LOGO
Delta-AX features a routed Wharfedale Pro logo.
This fresh design helps to distinguish between the original Delta-A models and the updated Delta-AX models.
It is also a logo to be proud of. A logo that lets your audience know that the sound of your even will be of the highest possible quality.
Specifications:
| Model Name | DELTA-AX15B |
|---|---|
| System Type | Active 15” Subwoofer |
| Frequency Response (+/-3 dB) | 42 Hz – 200 Hz |
| Calculated Maximum SPL @1 m | 130 dB |
|
Low Frequency Transducer – Size (mm / inches) |
404 mm / 15″ |
| Coil Size (mm / inches) | 101.6 mm / 4″ |
| Impedance | 8 Ω |
| Amplifiers | |
| Low-Frequency Power Amplifier RMS | 900 w (Class D) |
| High-Frequency Power Amplifier RMS | NA |
| Amplifier Protection | Yes |
| Power On Protection | Power switch on/off mute |
| Thermal Protection | Amplifier Shut Down. Auto Reset |
| Low Line Voltage Shut Down | 80% Nominal Line Voltage |
| Driver Protection | Yes |
| DC and Short Protection | Yes |
| Clip Limiter | Turns on Appro x 900 w Output |
| Limiter Indicator | Red LED |
| Power Indicator | Green LED |
| Connectors | |
| Input A – type | Balanced |
| Input Sensitivity | Line:0 dBu |
| Maximum Input Level | 22 dBu |
| Input Connector | TRS jack and Female XLR |
| Input Impedance | Balanced:20 KΩ Unbalanced:10 KΩ |
| Line Output Connector | Male XLR Connector |
| Impedance Balanced | Balanced: 200 Ω Unbalanced:100 Ω |
| Loop Gain | 0 dB |
| AC Power details – Power Supply | High Efficiency SMPS |
| AC Power Options | AC100-120 V~ / 220-240 V~,50/60 HZ |
| Power On Indicator | Green LED |
| Hardware – Rigging | |
| Enclosure Material and finish | 15 mm Plywood |
| Colour Options | Black Rhino Paint |
| Grille Material & Finish | |
| Unpacked dimensions – Height | 471 mm / 18.54″ |
| Width (Front) | 471 mm / 18.54″ |
| Width (Back) | 471 mm / 18.54″ |
| Depth | 600 mm / 23.62″ |
| Packed Dimensions – Height | 556 mm / 21.89″ |
| Width (Front) | 672 mm / 26.46″ |
| Width (Back) | 672 mm / 26.46″ |
| Depth | 543 mm / 21.38″ |
| Net Weight (kg / lbs) | 33.1 kg / 72.82 lbs |
| Gross Weight (kg / lbs) | 36.7 kg / 80.74 lbs |
