Features
- Quickly trace and identify cables among lots of unknowncables.
- Check continuity of Lan cables.
- Track the cables or wires, and diagnose the breakage.
- Visible indication: pin-to-pin cable map for individualcable (not by pairs).
- Low Voltage alarm function.
- Earphone permits use in noisy environments.
- LED light assists use in dark corners.
Specification
| NF-801 Transmitter specifications |
|
| Tone frequency | 200Hz |
| Max. distance of transmission | Up to 2 kilometers |
| Max. working current | Less than 10mA |
| Volume Regulate Function | Audio volume level control |
| Tone mode | 2 Tones, adjustable |
| Compatible connectors | RJ11,RJ45 |
| Max. signal voltage | 8Vp-p |
| LED lights display | Wiremap, tone, tracing |
| Voltage protection | AC 60V/DC 42V |
| Battery Type | DC9.0V battery x 1pc (included) |
| Dimensions (LxWxD) | 15 x 3.7 x 2cm |
| NF-801 Receiver specifications |
|
| Frequency | 200kHz |
| The Max. working current | Less than 30mA |
| Earphone jack | 1 |
| Battery Type | DC9.0V x1pc (included) |
| Dimensions (LxWxD) | 12.2 x 4.5 x 2.3cm |
