TF06474 12.6V 150MA MAINS TRANSFORMER 1.89VA CENTRE TAPPED ARLEC STADIUM 6474

TF06474 12.6V 150MA MAINS TRANSFORMER 1.89VA CENTRE TAPPED ARLEC STADIUM 6474

TF06474 12.6V 150MA MAINS TRANSFORMER 1.89VA CENTRE TAPPED ARLEC STADIUM 6474

Sold Out $31.50

Specifications:

Primary voltage: 240VAC only +5% 50Hz
Secondary Voltage: 12.6V CT @ 150mA
Magnetising current: ~20mA
Total Power rating: 1.9VA
Temp rise above ambient at rated output: ~40°C
Regulation (Typical): ~7.5%
Weight: ~124 grams
Secondary Connection: 200mm flying leads.
Primary Connection: 200mm flying leads
Dimensions: A-36, B-54, C-63, D-37 mm
